Victron Energy Lithium Smart Battery 12,8V/200Ah
zoom_out_map
chevron_left chevron_right

Victron Energy Lithium Smart Battery 12,8V/200Ah

LiFePO4 Lithium Batteries

• With integrated cell balancing

• Can be parallel and series connected

• Bluetooth app available to monitor cell voltage and temperature

€2,299.00
Tax included
block DELIVERY TIME 10 DAYS

Description

Why lithium-iron-phosphate?

Lithium-iron-phosphate (LiFePO4 or LFP) is the safest of the mainstream li-ion battery types. The nominal voltage of a LFP cell is 3,2V (lead-acid: 2V/cell). A 12,8V LFP battery therefore consists of 4 cells connected in series; and a 25,6V battery consists of 8 cells connected in series.

Rugged

A lead-acid battery will fail prematurely due to sulfation:

  • If it operates in deficit mode during long periods of time (i.e. if the battery is rarely, or never at all, fully charged).
  • If it is left partially charged or worse, fully discharged (yacht or mobile home during wintertime).

A LFP battery does not need to be fully charged. Service life even slightly improves in case of partial charge instead of a full charge. This is a major advantage of LFP compared to lead-acid. Other advantages are the wide operating temperature range, excellent cycling performance, low internal resistance and high efficiency (see below). LFP is therefore the chemistry of choice for very demanding applications.

Efficient

In several applications (especially off-grid solar and/or wind), energy efficiency can be of crucial importance. The round trip energy efficiency (discharge from 100% to 0% and back to 100% charged) of the average leadacid battery is 80%. The round trip energy efficiency of a LFP battery is 92%. The charge process of lead-acid batteries becomes particularly inefficient when the 80% state of charge has been reached, resulting in efficiencies of 50% or even less in solar systems where several days of reserve energy is required (battery operating in 70% to 100% charged state). In contrast, a LFP battery will still achieve 90% efficiency under shallow discharge conditions.

Size and weight

Saves up to 70% in space Saves up to 70% in weight

Expensive?

LFP batteries are expensive when compared to lead-acid. But in demanding applications, the high initial cost will be more than compensated by longer service life, superior reliability and excellent efficiency.

Bluetooth

With Bluetooth cell voltages, temperature and alarm status can be monitored. Very useful to localize a (potential) problem, such as cell imbalance.

Data sheet

LiFePO4 12,8V/200Ah - Smart
350 mm
470 mm
280 mm
41 kg
Data sheet
Height
297 mm
Width
425 mm
Depth
274 mm
Weight
42 kg

Attachments

VE_LiFePO4_bat

Datasheet Victron Energy LiFePO4 smart batteries

Download (302.27k)
VE_BMS

Datasheet Victron Energy BMS VE-BUS

Download (610.78k)
VE_miniBMS

Datasheet Victron Energy miniBMS

Download (284.82k)
